Pulsar PSR3584 Gen3 Dual Ball Bearing Super Core 4" Inlet

Pulsar Turbo Systems PSR3584 Gen3 Super Core is a high-performance dual ceramic ball bearing center assembly rated at approximately 1000 FWHP. This listing is for the Super Core only and does not include a turbine housing.

Product Specifications

• Manufacturer: Pulsar Turbo Systems
• Manufacturer Part Number: 112135219
• Series: PTX Gen3
• Turbo Model: PSR3584 Gen3
• Bearing System: Dual Ceramic Ball Bearing
• Power Rating: 1000 FWHP
• Maximum Airflow: ~90 lb/min
• Compressor Wheel: 67 x 84 mm
• Compressor Wheel Design: 10-blade Gen2 billet compressor wheel with extended tapered tip
• Turbine Wheel: 74 x 66 mm
• Turbine Wheel Design: Inconel 713C 10-blade high-flow turbine wheel
• Compressor Inlet: 4" hose
• Compressor Outlet: 2.5" hose
• Turbine Inlet: No turbine housing included
• Turbine Outlet: No turbine housing included
• Turbine Housing: N/A - Super Core
• Wastegate: N/A - turbine housing not included
• Oil Feed: -4 AN to oil restrictor
• Oil Drain: Standard T3 flange
• Water Ports: M14 x 1.5

Important: Turbine housing is not included. Select a compatible PTX35/PSR3584 Gen3 turbine housing for the intended manifold flange, outlet and A/R configuration.

Pulsar recommends water cooling for improved turbocharger durability.
