Brian Crower BC0340 Scion 2AZ-FE Single Valve Spring / Titanium Retainer / Seat Kit

Brian Crower BC0340 is an application-specific valve spring and retainer package for Scion 2AZ-FE. The matched components are intended to provide controlled spring pressure and stable valvetrain operation in performance applications when installed to the correct height and clearance.

Fitment / Application

Scion 2AZ-FE

Product Details

• Manufacturer: Brian Crower
• Manufacturer Part Number: BC0340
• Product Type: Valve Spring & Retainer Kit
• Fitment / Application: Scion 2AZ-FE
• Spring Type: Single
• Spring Part Number: BC1340
• Retainer: BC2340
• Retainer Material: Titanium
• Kit Includes: Valve springs, Retainers, Spring seats

Brian Crower Spring Specifications

• Free Length: 1.628"
• Seat Pressure: 1.300" @ 82 lbs
• Open Pressure: 0.900" @ 188 lbs
• Coil Bind: 0.810"
• Net Cam Lift: 0.425" / 10.8 mm
• Spring Seat: BC2930

Fitment Note

We identify many performance components by engine family rather than by every individual chassis. Verify the engine code, cylinder head/valvetrain configuration, and required supporting components before ordering, especially on engine swaps or modified vehicles.

Always verify installed height, coil-bind clearance, retainer-to-seal/guide clearance, and camshaft lift before final engine assembly.
