Brian Crower BC0070 Honda D16Y8/D16Z6 Single Valve Spring / Titanium Retainer Kit

Brian Crower BC0070 is an application-specific valve spring and retainer package for Honda D16Y8/D16Z6. The matched components are intended to provide controlled spring pressure and stable valvetrain operation in performance applications when installed to the correct height and clearance.

Fitment / Application

Honda D16Y8/D16Z6

Product Details

• Manufacturer: Brian Crower
• Manufacturer Part Number: BC0070
• Product Type: Valve Spring & Retainer Kit
• Fitment / Application: Honda D16Y8/D16Z6
• Spring Type: Single
• Spring Part Number: BC1070
• Retainer: BC2070
• Retainer Material: Titanium
• Kit Includes: Valve springs, Retainers

Brian Crower Spring Specifications

• Free Length: 2.231"
• Seat Pressure: 1.975" @ 58 lbs
• Open Pressure: 1.500" @ 154 lbs
• Coil Bind: 1.320"
• Net Cam Lift: 0.490" / 12.45 mm
• Spring Seat: Uses OEM spring seat

Fitment Note

We identify many performance components by engine family rather than by every individual chassis. Verify the engine code, cylinder head/valvetrain configuration, and required supporting components before ordering, especially on engine swaps or modified vehicles.

Always verify installed height, coil-bind clearance, retainer-to-seal/guide clearance, and camshaft lift before final engine assembly.
