Borg Warner S360 S300SX3 8375 60/68 Turbo Charger 177272 .91 A/R with T4 Housing

$929.99

  • Brand: BorgWarner
  • Availability: 1 In Stock
  • SKU: IF_E097C957
  • Barcode:

In Stock & Ready to Ship! Up for sale is a BorgWarner S360 8375 S300SX3 60/68 TurboCharger with T4 Divided .91 A/R and 3/4 Marmon 4.21" exhaust housing. Specifications: Compressor Wheel Inducer 60mm Center Cartridge Journal Bearing Compressor Housings 4.0" / 3.0" Compressor Wheel OD (Exducer)    83.47mm Please review BorgWarner's turbo systems warranty, they offer a 12 month limited warranty. AirWerks Turbochargers...

Tags:

In Stock & Ready to Ship!

Up for sale is a BorgWarner S360 8375 S300SX3 60/68 TurboCharger

with T4 Divided .91 A/R and 3/4 Marmon 4.21" exhaust housing.

Specifications:

Compressor Wheel Inducer 60mm

Center Cartridge Journal Bearing

Compressor Housings 4.0" / 3.0"

Compressor Wheel OD (Exducer)    83.47mm


Please review BorgWarner's turbo systems warranty, they offer a 12 month limited warranty.

AirWerks Turbochargers Overview

AirWerks turbochargers are expertly crafted for motorsport enthusiasts, engine retrofits, and drivers seeking enhanced performance from factory turbocharged vehicles. Designed with a focus on drag racing, pulling, and road racing, they have earned a solid reputation for durability and high-performance capabilities. Whether you need a straightforward replacement, a turbocharger upgrade, or a compact solution for tight spaces, BorgWarner’s AirWerks series offers a reliable choice for various applications.

Performance and Design
Built with twin hydrodynamic journal bearings, AirWerks turbochargers deliver exceptional responsiveness, achieving over 70 PSI of boost. They feature a high-pressure compressor stage, extended-tip technology, and a highly efficient turbine stage, ensuring robust performance and reliability.

Borg Warner S360 – 60mm S300SX3 8375 - 177272

The S300SX 8375 has long been recognized as an excellent choice for entry-level twin scroll turbos with journal bearings. It features a 68 lb/min 7-blade extended tip compressor wheel and a 10-blade 75.9mm inconel turbine wheel with a 4340 shaft, making it ideal for applications producing between 450-550whp.

It is offered in multiple configurations, including a 0.88 A/R T4 single scroll (open volute, undivided) and 0.91, 1.00, and 1.10 A/R T4 divided housings. As one of the smaller options in the S300SX series, it utilizes a 7-blade extended-tip compressor wheel with a 60mm inducer and 83mm exducer. The turbo comes standard with a 0.91 A/R twin scroll T4 housing, though upgrading to a 1.00 A/R or 1.10 A/R twin scroll housing is advisable for boost levels exceeding 25 psi. A 0.88 A/R T4 single scroll variant is also available for undivided setups. This turbo is oil-cooled and uses journal bearings exclusively, with no water cooling or ball bearing CHRA options. Comparable to a twin scroll GT3582R, it offers superior boost potential at a more affordable price.

Compressor Specifications:
Compressor Type: Airwerks "S" Generation with Extended Tip
Compressor Wheel OD (Exducer): 83mm
Compressor Wheel Inducer: 60mm

Compressor Housing Connections:
Inlet: 4.0″ Hose Coupler
Outlet: 3.0″ Hose Coupler

Turbine Specifications:
Turbine Type: Inconel S300SX Turbine Wheel
Turbine Wheel OD: 76mm

Housing Size and A/R ratio: The S300SX3 8375 (S360) is offered in six turbine housing configurations:

    <>
  • T4 .91A/R Twin Flow
  • T4 .88A/R Open Flow
  • T4 1.00A/R Twin Flow
  • T4 .88A/R Open Flow 90° Outlet
  • T4 .91A/R Twin Flow 90° Outlet
  • T4 1.00A/R 90° Outlet Twin Flow

Turbine Outlet: 3/4 Marmon 4.21"
