Icon Piston Set IC858.040; 4.400" Bore 2V for Ford 501 BBF Stroker

$740.00

  • Brand: Icon Piston
  • Availability: 1 In Stock
  • SKU: IC858.040
  • Barcode:

ICON Premium Forged Pistons ICON premium forged pistons are made from high-strength, heat-treated T-6 2618 primary aluminum alloy. They feature a diamond-machined skirt, head, mini-grooves, pin bore, gas accumulator, ring grooves, and pressure-drilled pin hole oiling. The pistons have a V-rib design for light weight, strength, and maximum piston cooling. Compare weight, performance, design, and cost—and you will win with...

Tags:

ICON Premium Forged Pistons

ICON premium forged pistons are made from high-strength, heat-treated T-6 2618 primary aluminum alloy. They feature a diamond-machined skirt, head, mini-grooves, pin bore, gas accumulator, ring grooves, and pressure-drilled pin hole oiling. The pistons have a V-rib design for light weight, strength, and maximum piston cooling. Compare weight, performance, design, and cost—and you will win with ICON!



Engine Piston Set Model or Series:
 Premium
Make: Ford
Engine: 501 BBF (460 Stroker)
Bore: 4.400" Bore
Stroke: 4.150" Stroke
Rod Length: 6.800" Rod
Compression Height: 1.425"
Crown Volume: -3.4cc Flat Top (2V)
Cylinder Head Volume to Calculate Compression Ratio: 75cc
Compression Ratio: 12.7:1
Pin Diameter: .990" Pin
Piston Material: Forged 2618 Alloy
Ring Lands: 1/16, 1/16, 3/16"
Wrist Pin Fitment: Pressed-Fit or Floating
Notes: Centered pin. For use with Ford/Edelbrock type heads. Connecting rod small end width - 1.250� max. Uses (BBC) .9898� diameter wrist pin.

Quantity: Sold As Set (8/pkg)
