Wired By Frank Custom K-series Engine Harness

Wired by Frank Customer Engine Harness

HARNESS CONNECTOR LIST:

VTEC solenoid
VTC
Oil pressure sending unit
Crank Sensor (CKP)(02-04 K20 style)
Coils 1-4
Cam (CPS) Exhaust Side
Top Dead Center sensor (TDC)Intake Side
Engine Coolant Temp (ECT) (02-04 K24 style)
Knock Sensor (KS)(02-04 K24 syle)
Intake Air Temperature (IAT)
Alternator(02-04 K24 style)
Manifold Air Pressure (MAP)
Throttle Position Sensor (TPS)

Idle control motor
Electronic speed sensor (VSS)
Injectors 1-4
h20 sending unit (for gauge cluster)
Reverse Lights
Reverse Lockout solenoid
Starter signal
Computer plugs Haltech Elite 1500
Power distribution cap
Ground
2 Extra Wires

Please specify if vehicle is running DBW!

Engine to chassis ground kit is an additional $100.
